HVL-F28RM External Flash with Wireless Radio Control

Model: HVL-F28RM
RM 1,099.00
1

1. Prices indicated refer to Suggested Retail Price and may change from time to time without prior notice.

  • Overview

    Small, powerful, radio wireless flash



    Product image

    Made by Sony for stunning images

    The HVL-F28RM offers exceptional performance and stability with the α7 series. It offers versatile features and detailed control plus the solid reliability needed for professional and advanced amateur applications in a compact, portable unit.

    Usage image

    An ideal GN28 flash for compact mirrorless cameras

    The flash head and internal layout of the HVL-F28RM have been redesigned for reduced size and greater portability, making it a perfect match for compact mirrorless cameras. Although it slips easily into a pocket, the HVL-F28RM delivers output that rivals the high-end HVL-F45RM at the same illumination angle and can be effectively used for bounce lighting in a wide range of shooting situations.

    High reliability and durability in a compact flash unit



    Product image

    Metal shoe foot with rugged side frame

    The Multi Interface shoe features a newly developed metal shoe foot with rugged side frame, significantly increasing strength and reliability.

    Illustration

    Dust and moisture resistant design

    Like Sony’s high-end flash units, the HVL-F28RM features a dust and moisture design that can withstand the rigours of professional work, even in challenging outdoor environments.

    Usage image

    Effective overheating prevention

    An optimised flash control algorithm provides excellent flash performance while effectively preventing overheating for long-term stability and reliability.

    Product image

    Comprehensive control from
    the camera

    Flash compensation, light ratio, and other detailed flash parameters can be controlled directly from a compatible camera. A camera custom key can be assigned to call up the flash parameter display so that adjustments can be made while looking through the viewfinder and gripping the camera. Flash parameters are shown in the selected camera display language.

    High-end features and control in a portable unit



    Product image



    Direct output adjustment for quick operation

    Dedicated light output level buttons (LEVEL -/+ buttons) directly control light output and flash compensation for fast, efficient operation. The light output of other wirelessly paired flash units can also be adjusted in this way for a smooth, stress-free workflow.
    Example image

    Comprehensive flash features

    The HVL-F28RM also includes the same high-speed sync, multi-flash, and other flash features as the HVL-45RM and HVL-60RM.








  • Features
    Small, powerful, reliable, radio wireless flash

    Small, powerful, reliable, radio wireless flash

    This high-output GN28 flash offers the type of optimised performance and control that only a genuine Sony product can provide. It can be controlled directly from the camera and is small enough to fit in a pocket while offering professional durability as well as wireless radio communication for a wide range of applications.

    Effective overheating prevention

    Effective overheating prevention

    An optimised flash control algorithm provides excellent flash performance while effectively preventing overheating for long-term stability and reliability.

    Stable radio wireless communication

    Stable radio wireless communication

    The HVL-F28RM features stable radio wireless communication. One HVL-F28RM that will function as a commander can be mounted on a compatible camera and paired with other off-camera HVL-F28RM units that will function as a receiver. Radio communication provides reliable communication over longer distances that are possible with optical communication, even in bright sunlight or when there are obstacles between the camera and subject. Slow sync, rear-curtain sync, and multi flash are supported.

    Multi flash radio control

    Multi flash radio control

    When used as a flash commander the HVL-F28RM can control up to 15 flash and/or receiver units in 5 groups at distances of up to 35 m/114 ft  for extraordinary lighting control versatility.

    Comprehensive control from the camera

    Comprehensive control from the camera

    Flash compensation, light ratio, and other detailed flash parameters can be controlled directly from a compatible camera, and a custom key assignment can allow adjustments to be made while looking through the viewfinder. Flash parameters are shown in the selected camera display language.

    Lighting tailored to individual scenes

    Lighting tailored to individual scenes

    With powerful output that rivals the HVL-F45RM, plenty of light is available for bounce applications, and the flash angle can be set as required via 0, 20, 40, 60, 80, and 120 degree click stops. A lock is provided at the 0-degree position to prevent unwanted angle changes in hectic shooting situations.

    Metal shoe foot with rugged side frame

    Metal shoe foot with rugged side frame

    The Multi Interface shoe features a newly developed metal shoe foot with rugged side frame, significantly increasing strength and reliability.

    Reliable in harsh outdoor conditions

    Reliable in harsh outdoor conditions

    Like all of Sony’s high-end flash units, the HVL-F28RM features a dust and moisture resistant design that contributes to high reliability in harsh outdoor.

    Direct light level control

    Direct light level control

    Dedicated + and – LEVEL buttons allow direct, speedy light output and flash compensation control, and can also be used to control the same parameters on other wirelessly paired flash units for smooth, efficient workflow.

    Through-the-lens (TTL) wireless flash

    Flash output can be accurately determined by through-the-lens light measurement, even when shooting wirelessly. The position and direction of the flash can be adjusted to soften shadows and highlights when shooting a subject from the front, or to add shadows for a sense of depth when needed. Wireless flash ratio control is available.

    High-speed sync (HSS)

    High-speed sync (HSS)

    Normal maximum flash sync speeds mean that the shutter speed must be stopped down when using daylight fill flash, making it difficult to produce background bokeh. High-speed sync allows the flash to be synchronised to the full range of shutter speeds so that large apertures can be used to create bokeh wherever desired.

    Test flash mode

    Test flash mode

    The test flash mode enables you to check shadows on the subject before taking photos, and also to check the light level using an external flash meter, which is essential for studio photography. The light level of the test flash depends on the light level setting in manual flash (M) mode, and the flash unit fires with a light level of 1/1 in through-the-lens (TTL) mode.

    Multi/Micro USB terminal

    Multi/Micro USB terminal

    The flash unit can be connected to a computer via its Multi/Micro USB terminal for convenient software updating.

    Flash control based on face detection

    Flash control based on face detection

    The HVL-F28RM works with the face detection capabilities of compatible cameras to balance flash output with ambient light conditions so that subject's face is rendered with lifelike, accurate white balance.

    Auto white balance adjustment

    Colour temperature information is transferred from the flash unit to the camera to ensure accurate white balance for natural-looking colours. With compatible cameras flash output is automatically balanced with ambient light conditions so that skin tones are rendered with ideal white balance.

  • Specifications

    Basic information

    Dimensions (Approx.)

    W 65.1mm X H 83.5mm X D 91.4mm (2 5/8inches × 3 3/8inches × 3 5/8inches)

    Weight(Approx.)

    219g (7.8 oz) (only main unit)

    Type

    Type

    Auto electronic flash (clip-on type) with pre-flash metering

    Shoe type

    Multi Interface Shoe.

    Flash Head(Light-emitting unit)

    Maximum Guide number

    28 (Flash coverage setting 50mm, ISO100・m)

    Flash coverage

    50mm, Angle of view at 24mm focal length is also covered with the wide panel

    Flash mode

    TTL/MANUAL/MULTI

    Flash Duration (Approx.)

    Within 1.6ms (1/1 MANUAL)

    Color Temperature (Approx.)

    5500K

    Frequency (Approx.)

    0.1-6.4 seconds(Alkaline battery)/0.1-4.1 seconds(Ni-MH battery)

    Repetition (Approx.)

    More than 110 times(Alkaline battery)/More than 130 times(Ni-MH battery)

    Continuous flash performance

    40 flashes at 10 flashes per second

    Bounce flash

    Yes

    Bounce angle

    Up 120deg (0deg/20deg/40deg/60deg/80deg/120deg)

    Test flash

    Yes

    Flash control

    Flash control using pre-flash (P-TTL/ADI)

    Flash compensation

    Yes

    Power Level switching

    25 levels (1/1-1/256) 1/3 steps

    High-speed sync(HSS)

    Yes

    Modeling flash

    Yes

    Built-in wide panel

    Yes (24mm)

    Built-in bounce sheet

    Yes

    AF illuminator

    AF illuminator

    -

    Operating Range (Approx.)

    -

    Radio controlled wireless function

    Radio Control Wireless Function

    Yes (commander/receiver)

    Frequencies

    2.4 GHz band

    Channels

    14 Channels (Auto/manual)

    Communication Distance (Approx.)

    35m

    Groups

    3 groups (TTL/MANUAL),5 groups (group flash photography)

    Maximum Flash units

    15 units

    Lighting ratio control

    3 groups (TTL)

    Optical control wireless function

    Optical Controlled Wireless Flash

    -

    Channels

    -

    Communication Distance (Approx.)

    -

    Groups

    -

    Lighting ratio control

    -

    LED light function

    Center Luminance Intensity (Approx.)

    -

    Lighting Distance (Approx.)

    -

    Focal length supported

    -

    Continuous Lighting Time (Approx.)

    -

    Color Temperature (Approx.)

    -

    Power Level switching

    -

    Other functions

    Auto zoom control optimized for image sensor size

    -

    Flash distribution setting

    -

    Auto WB Adjustment

    Yes

    Custom key settings

    -

    Memory settings

    Yes

    Remote release

    -

    Display

    LCD panel

    -

    Charge progress indicator

    -

    External connectors

    Sync terminal

    -

    Multi/Micro USB terminal

    Yes

    Power source

    Power source

    Two AA-size alkaline or Ni-MH batteries

    External Battery Adaptor

    -

    Other features

    Dust and moisture resistant design

    Yes
